High quality deep groove ball bearing 6020
Quick Details
Structure: Deep Groove
Type: Ball Brand
Name: NSK
Bore Size: 100 mm
Outside Diameter: 150 mm
Model Number: 6020
Precision Rating: P0 P2 P3 P4 P5 P6
Number of Row: Single Row
Material: Chrome steel Gcr15
certificate: ISO9001:2000
cage: steel,cage,brass
Noise level: Z1,Z2,Z3
samples: available
Thickness: 24 mm
Weight: 1.26 kg
HS code: 8482109000
Packaging: single plastic bag,color box
Deep groove ball bearing type:
1) with a ring or dust cover bearings (2RS or ZZ)
2 )with a dust cover: single-sided or double-sided iron dust cover. (ZZ)
3) with a non-contact rubber seals: single-sided or double-sided non-contact seals. (2LS)
4) with contact rubber seals: single-sided or double-sided contact seals in contact with the inner ring.
N: outer ring with a groove
NR: outer ring with groove and snap ring.
Bearing characteristics
Deep groove ball bearing is the most representative of the rolling bearing, widely used. Suitable for high speed and high speed running, and very durable, need not often maintenance. These bearing small friction coefficient, high limit speed, simple structure, low manufacture cost, easy to achieve high manufacture precision. Size range and variety in form, used in precision instrument, low noise motors, automobiles, motorcycles and general machinery and other industries, is the most widely used type of bearings in machinery industry. Mainly bear radial load, also can withstand a certain amount of axial load.
Application ofbearing 6020:
Restaurant equipment, renewable crusher, food sterilization equipment, packing, bar cutting machine, hydraulic test pump, tensile testing machine, drying machine, ball mill, medicine mixing equipment, binding machine, pharmaceutical packaging machinery, leather measuring machine, belt pulley, welding machine, low noise type cooling tower, cold welding, cutting equipment, and so on.
Deep groove ball bearing 6000 series:
Bearing No. bore diameter outer Diameter Thickness Weight(KG)
6000 10 26 8 0.019
6001 12 28 8 0.023
6002 15 32 9 0.032
6003 17 35 10 0.039
6004 20 42 12 0.07
6005 25 47 12 0.079
6006 30 55 13 0.117
6007 35 62 14 0.156
6008 40 68 15 0.194
6009 45 75 16 0.246
6010 50 80 16 0.264
6011 55 90 18 0.384
6012 60 95 18 0.418
6013 65 100 18 0.438
6014 70 110 20 0.607
6015 75 115 20 0.645
6016 80 125 22 0.855
6017 85 130 22 0.895
6018 90 140 24 1.17
6019 95 145 24 0.567
6020 100 150 24 1.26
6021 105 160 26 1.6
6022 110 170 28 1.97
6024 120 180 28 2.67
6026 130 200 33 3.92
6028 140 210 33 4.15
6030 150 225 35 4.84
TIANJIN SEMRI BEARING TECHNOLOGY CO.,LTD
If you need any types bearing,please contact us.We will do our best service for you.
http://www.semribearing.com/
