Low price OEM truck hub wheel Bearing DAC2562206
Quick Details
Structure: Taper
Type: Roller
Brand Name: SEMRI
Bore Size: 10 - 180 mm
Outside Diameter: 25 - 370 mm
Model Number: DAC2562206
Precision Rating: P0/P2/P4/P5/P6
Seals Type: open
Number of Row: Double Row
Place of Origin: Shandong, China (Mainland)
Material: GCr15,Carbon steel
Noise grades: z1,z2,z3,z4
Certification: ISO9001:2000
Main market: North America,Southeast Asia,Mid East,Arica,Easter
Groove type: spherical raceway
Weight: 0.45kg
Type,Structure and Characteristics
The rolling elements perform the real rotating movement on the raceway;the synthesized force from the inner and outer ring raceways guides the rollers,pressing them to the large rib on the inner ring.
Metric and inch series are considered standard and both systems are widely used.
The inner ring,rollers and cage can be separated as a unit,or the CONE,from the outer ing,or the CUP.The CUP and cone are
called sub-units,Sub-unit dimension for the nominal cup small inside diameter and bearing contact angle,are standardized
by ISO and ABMA and are compatible between sun-units,Double row and four row bearings are available in addition to single row in addition to single row bearings.
Features
-The inner and outer ring raceways and rollers of these bearings are made with a taper so that the surface planes of the raceways and roller axis meet at a point.
-The rollers are guided by a flange on the inner ring.Tapered roller bearings are separable, and have the following components: outer ring,inner ring and roller assembly.
-The non-separable inner ring and roller assembly is called the 'cone', and the outer ring is called the 'cup'. Internal clearanceis established during mounting by the axial position of the cone relative to the cup.
Applications
volvo rear wheel hub bearing DAC2562206 mainly used in motorcycle rear axle wheel hub, heavy machine tools' main shafts, big power reduction gears, axletree axle boxes, roller wheels of transportation devices, and the supporting rollers and working rollers of the rolling mills.
Prducts name
heavy truck hub wheel bearing
Bra0nd
KMYSeries
DAC2562206
ID size
taper roller hub bearing : 10mm - 180mm
Cage material
Steel , brass , Iron , plastic
Precision
taper roller bearing : PO P6 P5 P4 P2
Sealing
taper roller bearing : C3 C4 C1 C2 C0
Quality standard
ISO9001:2000 standard
Service
taper roller bearing OEM service
Delivery date
Normally ready goods and stock winthin 15 days
Payment terms
A:100% L/C at sight
B: 30% T/T in advance .70% against copy of B/L
Western Union,Paypal
Application
Mining. Metallurgy. Agriculture. Chemical. Textile. Dyeing.
Conveying machinery.
Package
taper roller bearing single color box
Details
the world's leading rolling bearing, seals, mechatronics,
services and lubrication system products, solutions and services to suppliers.
The main strength of the Group, including technical support, equipment maintenance
services, condition monitoring and technical training.
TIANJIN SEMRI BEARING TECHNOLOGY CO.,LTD
If you need any types bearing,please contact us.We will do our best service for you.
http://www.semribearing.com/
