SFI Nut Set With Precision Recirculating Ball Screw

Specifications and models

d

P  h0

Dw

D

A

B

L

W

H

X

Y

Z

Q


n

Ca

Coa

K

SFI01604-4

16

4

2.381

30

49

10

45

39

34

4.5

8

4.5

M6

4

640

1340

16

SFI01605-4

16

5

3.175

30

49

10

50

39

34

4.5

8

4.5

M6

4

780

1790

20

SFI01610-3

16

10

3.175

34

58

10

57

45

34

5.5

9.5

5.5

M6

3

833

1249

15

SFI02004-4

20

4

2.381

34

57

11

46

45

40

5.5

9.5

5.5

M6

4

670

1480

25

SFI02005-4

20

5

3.175

34

57

11

51

45

40

5.5

9.5

5.5

M6

4

1130

2380

25

SFI0205.8-4

20

5.08

3.175

34

57

11

51

45

40

5.5

9.5

5

M6

4

1130

2380

25

SFI02504-4

25

4

2.381

40

63

11

46

51

46

5.5

9.5

5.5

M6

4

760

1950

31

SFI02505-4

25

5

3.175

40

63

11

51

51

46

5.5

9.5

5

M6

4

1280

3110

35

SFI02510-4

25

10

4.763

46

72

12

85

58

52

6.5

11

6.5

M6

4

1944

3877

33

SFI03204-4

32

4

2.381

46

72

12

47

58

52

6.5

11

6.5

M6

4

860

3050

40

SFI03205-4

32

5

3.175

46

72

12

52

58

52

6.5

11

6.5

M8X1

4

1450

4150

40

SFI03210-4

32

10

6.35

54

88

15

90

70

62

9

14

8.5

M8X1

4

3390

7170

40

SFI04005-4

40

5

3.175

56

90

15

55

72

64

9

14

8.5

M8X1

4

1610

5330

49

SFI04010-4

40

10

6.35

62

104

18

93

82

70

11

17.5

11

M8X1

4

3910

9520

50

SFI05010-4

50

10

6.35

72

114

18

93

92

82

11

17.5

11

M8X1

4

4450

12500

65

SFI06310-4

63

10

6.35

85

131

22

98

107

95

14

20

13

M8X1

4

5070

6600

80

SFI08010-4

80

10

6.35

105

150

22

98

127

115

14

20

13

M8X1

4

5620

21300

90
