SFT Nut Set With Precision Recirculating Ball Screw

Specifications and models

d

h0

Dw

D

A

B

L

W

H

X

Y

Z

Q

n

Ca

Coa

K

SFT02005-5

20

5

3.175

44

67

11

57

55

52

5.5

9.5

5.5

M6

2.5X2

1546

3068

37

SFT02505-5

25

5

3.175

50

73

11

55

61

52

5.5

9.5

5.5

M8X1

2.5X2

1690

4460

46

SFT02510-2.5

25

10

6.35

68

102

15

70

84

82

9

14

8.5

M8X1

2.5X1

2440

4730

26

SFT03205-5

32

5

3.175

58

85

12

56

71

64

6.6

11

6.5

M8X

2.5X2

1880

5720

55

SFT03206-5

32

6

3.969

62

89

12

65

75

68

6.6

11

6.5

M8X

2.5X2

2520

7080

56

SFT03208-5

32

8

4.763

66

100

15

82

82

76

9

14

8.5

M8X

2.5X2

3230

8360

58

SFT03210-5

32

10

6.35

74

108

15

96

90

82

9

14

9

M8X

2.5X2

4280

11500

63

SFT03220-2.5

32

20

6.35

74

108

16

100

90

82

9

14

8.5

M8X

2.5X1

2680

6020

30

SFT04005-5

40

5

3.175

67

101

15

59

83

72

9

14

8.5

M8X

2.5X2

2026

7200

66

SFT04010-5

40

10

6.35

82

124

18

100

102

94

11

17.5

11

M8X

2.5X2

5300

14000

72

SFT04020-2.5

40

20

6.35

82

124

18

100

102

90

11

17.5

11

M8X1

2.5X1

2970

7370

38

SFT05010-5

50

10

6.35

93

135

18

103

113

98

11

17.5

11

M8X1

2.5X2

5940

18000

89

SFT05020-2.5

50

20

9.525

105

152

28

121

128

110

14

20

13

M8X1

2.5X1

7400

18700

89

SFT06310-5

63

10

6.35

108

154

22

105

130

110

14

20

13

M8X

2.5X2

6550

22700

107

SFT06320-2.5

63

20

9.525

122

180

28

127

150

130

18

26

18

M8X

2.5X1

8810

23200

73

SFT08010-5

80

10

6.35

130

176

22

105

152

132

14

20

13

M8X1

2.5X2

7200

28900

129

SFT08020-5

80

20

9.525

143

204

28

180

172

148

18

26

18

M8X1

2.5X2

6700

60100

175

SFT08020-7.5

80

20

9.525

143

204

28

240

172

148

18

26

18

M8X1

2.5X3

23500

89100

252
